SSH Servers

Create an integration to manage access to SSH servers

SSH servers are secure, remote access points that allow users to connect to and manage systems over encrypted connections.

Through this integration, Apono enables managing secure Just-in-Time (JIT) access to SSH servers. Admins can create access flows for specific SSH servers and define approval processes and access durations for different users, groups, and shifts.

When a user's access request is approved, Apono creates a certificate that grants access to the server and assigns the requester to the appropriate access group(s). Apono may also use the user's default Linux group.


hashtag
Prerequisites

Item
Description

hashtag
Integrate SSH servers

circle-check

You can also use the steps below to integrate with Apono using Terraform.

In step 10, instead of clicking Confirm, follow the Are you integrating with Apono using Terraform? guidance.

Follow these steps to complete the integration:

  1. On the tab, click SSH. The Connect Integration page appears.

  2. Under Discovery, click Next. The Apono connector section expands.

  3. From the dropdown menu, select a connector. Choosing a connector links Apono to all the services available on the account where the connector is located.

circle-info

If the desired connector is not listed, click + Add new connector and follow the instructions for creating a connector (, , , ).

  1. Click Next. The Integration Config page appears.

  2. Define the Integration Config settings.

Setting
Description
  1. Click Next. The Secret Store section expands.

  2. .

  3. Click Next. The Get more with Apono section expands.

Setting
Description
  1. Click Confirm.

chevron-right💡Are you integrating with Apono using Terraform?hashtag

If you want to integrate with Apono using Terraform, follow these steps instead of clicking Confirm:

  1. At the top of the screen, click View as Code. A modal appears with the completed Terraform configuration code.

Now that you have completed this integration, you can create that grant permission to your SSH instance.

Define the Get more with Apono settings.
Click to copy the code.
  • Make any additional edits.

  • Deploy the code in your Terraform.

  • Refer to Integration Config Metadataarrow-up-right for more details about the schema definition.

    Apono Connector

    On-prem connection serving as a bridge between an SSH server and Apono:

    • AWS

    • Azure

    • GCP

    Minimum Required Version: 1.4.0

    Learn how to update an existing , , , or connector.

    Apono Secret

    Value generated with the credentials of the SSH server user

    Create your secret based on your SSH server private key in base64 format.

    To find the private key in base64 format, run the following command.

    Apono does not store credentials. The Apono connector uses the secret to communicate with services in your environment and separates the Apono web app from the environment for maximal security.

    User with Key Pair Authentication

    Dedicated SSH server user account that authenticates with SSH key pairs

    In the sudoers file, add the following line to allow Apono to execute commands with sudo privileges without a password prompt.

    JSON List of Servers

    Structured list of SSH servers to which Apono will connect

    The following information should be provided for each server:

    • name: Unique identifier for the server

    • host: IP address or hostname of the server

    • user: (Optional) Username for the SSH connection. Default: apono

    • port: (Optional) SSH port number. Default: 22

    • tags: (Optional) Labels for grouping server resources for .

    User Groups

    (Optional) User groups representing access to the SSH servers

    Default: Default

    The default represents access to the server with the user's default Linux group.

    Integration Name

    Unique, alphanumeric, user-friendly name used to identify this integration when constructing an access flow

    Servers

    Minified JSON list of servers

    User Groups

    (Optional) Names of groups in the server representing the sudoer role

    User's Login Shell

    (Optional) Command-line interface program used to log in to an account via SSH

    User Key Name

    (Optional) Filename of the SSH key pair used for authentication

    Credential Rotation

    (Optional) Number of days after which the database credentials must be rotated

    Learn more about the Credentials Rotation Policy.

    User cleanup after access is revoked (in days)

    (Optional) Defines the number of days after access has been revoked that the user should be deleted

    Learn more about Periodic User Cleanup & Deletion.

    Custom Access Details

    (Optional) Instructions explaining how to access this integration's resources Upon accessing an integration, a message with these instructions will be displayed to end users in the User Portal. The message may include up to 400 characters. To view the message as it appears to end users, click Preview.

    Integration Owner

    (Optional) Fallback approver if no resource owner is found Follow these steps to define one or several integration owners:

    1. From the Attribute dropdown menu, select User or Group under the relevant identity provider (IdP) platform.

    2. From the Value dropdown menu, select one or multiple users or groups.

    NOTE: When Resource Owner is defined, an Integration Owner must be defined.

    Resource Owner

    (Optional) Group or role responsible for managing access approvals or rejections for the resource Follow these steps to define one or several resource owners:

    1. Enter a Key name. This value is the name of the tag created in your cloud environment.

    2. From the Attribute dropdown menu, select an attribute under the IdP platform to which the key name is associated. Apono will use the value associated with the key (tag) to identify the resource owner. When you update the membership of the group or role in your IdP platform, this change is also reflected in Apono.

    NOTE: When this setting is defined, an Integration Owner must also be defined.

    Catalogarrow-up-right
    AWS
    Azure
    GCP
    Kubernetes
    Associate the secret or credentials
    access flows
    SSH tile
    "key": "base64_private_key"
    "value": "<SSH_SERVER_PRIVATE_KEY>"
    cat /PATH-TO-KEY/key.pem | base64
    apono ALL=(ALL) NOPASSWD:ALL
    Kubernetes
    AWS
    Azure
    GCP
    Kubernetes
    dynamic access management

    Network Management

    Manage just-in-time, just-enough access to servers, RDPs, internal apps, and more

    Installing the Apono HTTP Proxy

    This proxy is used by Elasticsearch, Web App and more.

    hashtag
    Step By Step to installing the HTTP proxy

    hashtag
    Deploy with Kubernetes

    • Set the following env vars:

    KMS_KEY_ID value should be the OidcSignerKey created by Apono-Connector CloudFormation stack:

    • Install envoy proxy with helm:

    AWS EC2 SSH Servers

    How to integrate with your EC2 SSH Servers with Apono for JIT access

    hashtag
    Overview

    If users need to debug, develop or troubleshoot AWS EC2 SSH servers, they can request Just-in-Time access to them in Apono!

    Admins can create Access Flows with specific EC2 SSH servers and build approval and access duration flows for different users, groups, and shifts.

    Upon an approved request, Apono creates a certificate that grants access to the server and makes the requester a member of the group(s) representing the access they need. Apono may also use the user's default Linux group.

    Azure VM SSH Servers

    How to integrate with your Azure VM SSH Servers with Apono for JIT access

    hashtag
    Overview

    If users need to debug, develop or troubleshoot Azure VM SSH servers, they can request Just-in-Time access to them in Apono!

    Admins can create Access Flows with specific VM SSH servers and build approval and access duration flows for different users, groups, and shifts.

    Upon an approved request, Apono creates a certificate that grants access to the server and makes the requester a member of the group(s) representing the access they need. Apono may also use the user's default Linux group.

    hashtag
    How it works

    hashtag
    Prerequisites

    • Installed Apono connector with network access to the AWS EC2 SSH Servers

      • Minimal Apono connector version: 1.4.0 (visit the Connectors Pagearrow-up-right and update the connector if needed)

    • A user with a key pair authentication for Apono to your SSH servers with sudo permissions. Add this line to the sudoers file:

      • apono ALL=(ALL) NOPASSWD:ALL

    • Optional: User groups representing access to the servers. The default value is "Default", representing access to the server with the user's default Linux group.

    circle-info

    What's a connector? What makes it so secure?

    The Apono Connector is an on-prem connection that can be used to connect resources to Apono and separate the Apono web app from the environment for maximal securityarrow-up-right.

    Read more about the recommended Azure Installation Architecturearrow-up-right.

    hashtag
    Step-by-step guide

    1. In the Apono app, navigate to the Catalogarrow-up-right

    2. Pick the AWS EC2 SSH integration:

    3. Pick an existing connector or create a new one (see connector prerequisites)

    4. In the of your choice, create a secret for Apono with the following params:

      1. Key: base64_private_key

      2. Value: the SSH Server private key in base64 format (see SSH key prerequisites) To find the private key in base64 format, run this command : cat /PATH-TO-KEY/key.pem | base64

    5. Fill the config:

      1. Integration name: Give the integration a name of your choice

      2. User: set the name of the user you created in the for the Apono connector.

    circle-check

    Apono supports default access to SSH servers, even if no user groups were provided.

    This means users can always log in with their default Linux group.

    hashtag
    Results

    • You will be redirected to the Connected Integrationsarrow-up-right tab.

    • Make sure you see the AWS EC2 SSH integration as Active. The # of discovered SSH servers will appear in the table under Resources.

    • You can now create Access Flows for AWS EC2 SSH Servers!

    hashtag
    How it works

    hashtag
    Prerequisites

    • Installed Apono connector with network access to the Azure VM SSH Servers

      • Minimal Apono connector version: 1.4.0 (visit the Connectors Pagearrow-up-right and update the connector if needed)

    • A user with a key pair authentication for Apono to your SSH servers with sudo permissions. Add this line to the sudoers file:

      • apono ALL=(ALL) NOPASSWD:ALL

    • Optional: User groups representing access to the servers. The default value is "Default", representing access to the server with the user's default Linux group.

    circle-info

    What's a connector? What makes it so secure?

    The Apono Connector is an on-prem connection that can be used to connect resources to Apono and separate the Apono web app from the environment for maximal security.

    Read more about the recommended Azure Installation Architecture.

    hashtag
    Step-by-step guide

    1. In the Apono app, navigate to the Catalogarrow-up-right

    2. Pick the Azure VM SSH integration:

    3. Pick an existing connector or create a new one (see connector prerequisites)

    4. In the of your choice, create a secret for Apono with the following params:

      1. Key: base64_private_key

      2. Value: the SSH Server private key in base64 format (see SSH key prerequisites) To find the private key in base64 format, run this command : cat /PATH-TO-KEY/key.pem | base64

    5. Fill the config:

      1. Integration name: Give the integration a name of your choice

      2. User: set the name of the user you created in the for the Apono connector.

    circle-check

    Apono supports default access to SSH servers, even if no user groups were provided.

    This means users can always log in with their default Linux group.

    hashtag
    Results

    • You will be redirected to the Connected Integrationsarrow-up-right tab.

    • Make sure you see the Azure VM SSH integration as Active. The # of discovered SSH servers will appear in the table under Resources.

    • You can now create Access Flows for Azure VM SSH Servers!

    K8S_NAMESPACE=
    KMS_KEY_ID=
    helm install envoy-proxy https://apono-io.github.io/apono-helm-charts/envoy-proxy/envoy-1.0.4.tgz \
        --namespace $K8S_NAMESPACE \
        --set-string jwks=`aws kms get-public-key --key-id $KMS_KEY_ID --output text --query PublicKey | awk '{print "-----BEGIN PUBLIC KEY-----\n"$1"\n-----END PUBLIC KEY-----"}' | docker run -i danedmunds/pem-to-jwk:latest | awk '{print "{\"keys\":["$1"]}"}' | openssl base64 -A` \
        --set-string tls=true \ # if destination is https
        --set-string accessLogs=true \ # if you want access logs to be written
        --create-namespace
    User groups (Optional): The names of groups in the server representing the sudoer role (from a local server, puppet/chef, LDAP server, etc., depending on your network setup)
  • Secret: according to the Secret Store of your choice, insert the secret you created in step 4.

  • secret store
    prerequisitesarrow-up-right
    User groups (Optional): The names of groups in the server representing the sudoer role (from a local server, puppet/chef, LDAP server, etc., depending on your network setup)
  • Secret: according to the Secret Store of your choice, insert the secret you created in step 4.

  • Region (Optional): Select a specific Azure region to integrate. If you pick nothing, all regions will be synced.

  • secret store
    prerequisites

    Harmony SASE

    Empower just-in-time group membership for Harmony SASE via Apono

    Harmony Secure Access Service Edge (SASE) provides cloud-delivered network security, allowing organizations to streamline secure remote access with precision.

    Integrating Harmony SASE with Apono allows you to automate just-in-time access by temporarily adding users to specific Harmony SASE groups. This ensures the right users get access only when needed and are automatically removed when access expires, which is ideal for short-term projects or incident response. This approach strengthens security, reduces operational overhead, and supports least-privilege access practices.


    hashtag
    Prerequisites

    Item
    Description

    hashtag
    Integrate Harmony SASE

    circle-check

    You can also use the steps below to integrate with Apono using Terraform.

    In step 10, instead of clicking Confirm, follow the Are you integrating with Apono using Terraform? guidance.

    Follow these steps to complete the integration:

    1. On the tab, click Harmony. The Connect Integration page appears.

    2. Under Discovery, click Next. The Apono connector section expands.

    3. From the dropdown menu, select a connector. Choosing a connector links Apono to all the services available on the account where the connector is located.

    circle-info

    If the desired connector is not listed, click + Add new connector and follow the instructions for creating a connector (, , , ).

    1. Click Next. The Integration Config page appears.

    2. Enter a unique, alphanumeric, user-friendly Integration Name to identify the integration when constructing an access flow.

    3. From the dropdown menu, select a Region for the config’s activity.

    circle-info

    If you select the Apono secret manager, enter the value of your .

    1. Click Next. The Get more with Apono section expands.

    2. Define the Get more with Apono settings.

    Setting
    Description
    1. Click Confirm.

    chevron-right💡Are you integrating with Apono using Terraform?hashtag

    If you want to integrate with Apono using Terraform, follow these steps instead of clicking Confirm:

    1. At the top of the screen, click View as Code. A modal appears with the completed Terraform configuration code.

    hashtag
    Usage

    Now that the integration is complete, you can add Harmony SASE to define the grantees or resources in an access flow. This allows only the correct requesters to securely access your Harmony-synced groups, based on the access flow’s approval and provisioning rules.

    Follow the guidance in these articles to define the resource using Harmony SASE.

    Access flow type
    Resources

    F5 Network

    Create an integration to manage access to an F5 instance

    F5 Network provides an application delivery and security platform that optimizes performance, ensures availability, and protects applications across on-premises and cloud environments.

    Through this integration, Apono enables you to dynamically manage access to F5 resources by automating permissions and policies within your F5 Access Policy Manager (APM) instance.


    hashtag
    Prerequisites

    Item
    Description

    hashtag
    Create a dedicated Apono user

    Follow these steps to create a dedicated user for Apono:

    1. In F5, with a user-friendly name, such as apono-connector.

    2. Create a for the dedicated user to use during the Apono integration setup. Use the values from step 1 to generate the secret.

    circle-check

    You can also input the user credentials directly into the Apono UI during the integration process.

    You can now .


    hashtag
    Integrate F5 Network

    circle-check

    You can also use the steps below to integrate with Apono using Terraform.

    In step 10, instead of clicking Confirm, follow the Are you integrating with Apono using Terraform? guidance.

    Follow these steps to complete the integration:

    1. On the tab, click F5 Network. The Connect Integration page appears.

    2. Under Discovery, click Next. The Apono connector section expands.

    3. From the dropdown menu, select a connector. Choosing a connector links Apono to all the services available on the account where the connector is located.

    circle-check

    If the desired connector is not listed, click + Add new connector and follow the instructions for creating a connector (, , , ).

    1. Click Next. The Integration Config section expands.

    2. Define the Integration Config settings.

      Setting
      Description
    circle-info

    If you select the Apono secret manager, enter the following values:

    • Username: Enter the F5 Apono admin account username.

    • Password: Enter the F5 Apono admin account user password.

    1. Click Next. The Get more with Apono section expands.

    2. Define the Get more with Apono settings.

      Setting
      Description
    chevron-right💡 Are you integrating with Apono using Terraform?hashtag

    If you want to integrate with Apono using Terraform, follow these steps instead of clicking Confirm:

    1. At the top of the screen, click View as Code. A modal appears with the completed Terraform configuration code.

    hashtag
    Usage

    Now that the integration is complete, you can use F5 Network to define the resources in an access flow. This allows requesters to access F5 Network resources securely based on your approval and provisioning rules.

    Follow the guidance in these articles to define the resource using F5 Network:

    Click Next. The Secret Store section expands.

  • Associate the secret or credentials.

  • Click to copy the code.
  • Make any additional edits.

  • Deploy the code in your Terraform.

  • Refer to Integration Config Metadataarrow-up-right for more details about the schema definition.

    Harmony account access

    Harmony SASE user account hosted by Perimeter 81 or Check Point

    Apono connector

    On-prem connection serving as a bridge between an SSH server and Apono:

    • AWS

    • Azure

    • GCP

    Learn how to update an existing , , , or connector.

    Harmony API key

    Unique key generated in Harmony platform to authenticate connection with Apono Learn how to generate an API keyarrow-up-right with Harmony. NOTE: When creating the key, select all Key Permissions under the following categories for Apono to access your Harmony instance:

    • Members

    • Groups

    Apono secret

    Value generated with the credentials of the user you create

    Create your secret based on your Redis Cloud API account key and user key:

    • "api_key": <ACCOUNT_KEY>

    • "secret_key": <USER_KEY>

    Apono does not store credentials. The Apono Connector uses the secret to communicate with services in your environment and separate the Apono web app from the environment for maximal .

    Custom Access Details

    (Optional) Instructions explaining how to access this integration's resources Upon accessing an integration, a message with these instructions will be displayed to end users in the User Portal. The message may include up to 400 characters. To view the message as it appears to end users, click Preview.

    Integration Owner

    (Optional) Fallback approver if no resource owner is found Follow these steps to define one or several integration owners:

    1. From the Attribute dropdown menu, select User or Group under the relevant identity provider (IdP) platform.

    2. From the Value dropdown menu, select one or multiple users or groups.

    NOTE: When Resource Owner is defined, an Integration Owner must be defined.

    Resource Owner

    (Optional) Group or role responsible for managing access approvals or rejections for the resource Follow these steps to define one or several resource owners:

    1. Enter a Key name. This value is the name of the tag created in your cloud environment.

    2. From the Attribute dropdown menu, select an attribute under the IdP platform to which the key name is associated. Apono will use the value associated with the key (tag) to identify the resource owner. When you update the membership of the group or role in your IdP platform, this change is also reflected in Apono.

    NOTE: When this setting is defined, an Integration Owner must also be defined.

    Self Serve

    • Define permitted requesters

    • Define the resource

    Automatic

    • Define permitted requesters

    • Define the resource

    Catalogarrow-up-right
    AWS
    Azure
    GCP
    Kubernetes
    Harmony SASE workspace API Key
    Harmony tile

    Host and port of the F5 server hosting the Access Policy Manager (APM)

    Access Profile Id

    Identifier of the top-level access policy container that defines authentication and access logic

    Resource Assign Id

    Identifier of the rule set that represents the permission and assignment of webtop links to users

    Webtop

    Path to the Webtop object that presents assigned applications and links after user authentication

    Webtop Sections (Optional)

    Path used to group or organize webtop links within the Webtop resource

  • Click Next. The Secret Store section expands.

  • Associate the secret or credentials.

  • Integration Owner

    (Optional) Fallback approver if no is found Follow these steps to define one or several integration owners:

    1. From the Attribute dropdown menu, select User or Group under the relevant identity provider (IdP) platform.

    2. From the Value dropdown menu, select one or multiple users or groups.

    NOTE: When Resource Owner is defined, an Integration Owner

    Resource Owner

    (Optional) Group or role responsible for managing access approvals or rejections for the resource Follow these steps to define one or several :

    1. Enter a Key name. This value is the name of the tag created in your cloud environment.

    2. From the Attribute dropdown menu, select an attribute under the IdP platform to which the key name is associated. Apono will use the value associated with the key (tag) to identify the resource owner. When you update the membership of the group or role in your IdP platform, this change is also reflected in Apono.

    NOTE: When this setting is defined, an

  • Click Confirm.

  • Click to copy the code.
  • Make any additional edits.

  • Deploy the code in your Terraform.

  • Refer to Integration Config Metadataarrow-up-right for more details about the schema definition.

    F5 Admin Access

    User account with admin permissions to create a new user account

    F5 Network info

    Information for integrating Apono and F5:

    • F5 Hostname

    • Access Profile Id

    • Resource Assign Id

    • Webtop path

    • (Optional) Webtop Sections path

    Apono connector

    On-prem connection serving as a bridge between your Elastic Cloud instance and Apono:

    • AWS

    • Azure

    • GCP

    Learn how to update an existing , , , or connector.

    Integration Name

    Unique, alphanumeric, user-friendly name used to identify this integration when constructing an access flow

    Custom Access Details

    (Optional) Instructions explaining how to access this integration's resources Upon accessing an integration, a message with these instructions will be displayed to end users in the User Portal. The message may include up to 400 characters. To view the message as it appears to end users, click Preview.

    create a new admin user accountarrow-up-right
    secretarrow-up-right
    integrate F5 Network
    Catalogarrow-up-right
    AWS
    Azure
    GCP
    Kubernetes
    Define the resource (Self Serve Access Flows)
    Define the resource (Automatic Access Flows)
    F5 Network tile

    F5 Hostname

    RDP Servers

    Create an integration to manage access to an RDP server

    Microsoft Remote Desktop Protocol (RDP) enables users to connect to and control a remote computer or virtual machine over a network. It provides secure and efficient remote access to desktops, servers, and applications, allowing employees to work from anywhere with an internet connection.

    With this integration, Apono enables you to manage access to an RDP server with Connect permission or custom permissions group, so that only specific users or groups can provide remote access to resources in your environment on a temporary, as-needed basis.


    hashtag
    Prerequisites

    Item
    Description

    hashtag
    Configure the RDP server

    Before you begin integrating RDP with Apono, you must configure the Windows Remote Management (WinRM) service on a Windows machine to allow remote access using unencrypted and basic authentication.

    You can allow or communication.

    Follow these steps to configure the RDP server:

    1. Add the WinRM port 5985 to the allowlist in the server firewall.

    2. Turn on the WinRM firewall rule in the Windows server.

    3. Analyze and configure the WinRM service to allow remote management on the local machine.


    hashtag
    Integrate an RDP server

    circle-exclamation

    WinRM HTTPS requires a local computer Server Authentication certificate with a CN matching the hostname to be installed. The certificate must not be expired, revoked, or self-signed.

    circle-check

    You can also use the steps below to integrate with Apono using Terraform.

    In step 11, instead of clicking Confirm, follow the Are you integrating with Apono using Terraform? guidance.

    Follow these steps to complete the integration:

    1. On the tab, click RDP The Connect Integration page appears.

    2. Under Discovery, select one or multiple resource types for Apono to discover in all instances of the environment.

    3. Click Next. The Apono connector section expands.

    circle-check

    If the desired connector is not listed, click + Add new connector and follow the instructions for creating a connector (, , , ).

    1. Click Next. The Integration Config page appears.

    2. Define the Integration Config settings.

      Setting
      Description
    chevron-right💡Are you integrating with Apono using Terraform?hashtag

    If you want to integrate with Apono using Terraform, follow these steps instead of clicking Confirm:

    1. At the top of the screen, click View as Code. A modal appears with the completed Terraform configuration code.

    Now that you have completed this integration, you can that grant permission to your RDP server.

    Windows Domain Controller

    Create an integration to manage access to a Windows Domain Controller

    A Windows Domain Controller (DC) authenticates and authorizes users, enforcing security policies for computers within the domain. Through centralized user management and access control, the DC ensures that users can log into computers and access resources like applications and files based on their permissions.

    With this integration, Apono enables you to manage access to a Windows Domain Controller with Connect permission or a custom permissions group, so that only specific users or groups can provide remote access to resources in your environment on a temporary, as-needed basis.​


    hashtag
    Prerequisites

    "username": "F5_USERNAME",
    "password": "F5_PASSWORD"
    Kubernetes
    AWS
    Azure
    GCP
    Kubernetes
    security
    must be defined.
    Integration Owner
    must also be defined.
    Kubernetes
    AWS
    Azure
    GCP
    Kubernetes
    resource owner
    resource owners
    circle-info

    If a confirmation prompt appears after running the following command, enter y.

    1. Set the WinRM service configuration to allow unencrypted traffic.

    1. Enable basic authentication for the WinRM service. Basic authentication transmits credentials in cleartext.Shell

    You can now integrate an RDP server.

    Follow these steps to configure the RDP server:

    1. Add the WinRM port 5985 to the allowlist in the server firewall.

    2. Turn on the WinRM firewall rule in the Windows server.

    3. Analyze and configure the WinRM service to allow remote management on the local machine.

    circle-info

    If a confirmation prompt appears after running the following command, enter y.

    1. Enable basic authentication for the WinRM service. Basic authentication transmits credentials in cleartext.

    1. Configure WinRM HTTPS access on the target machine.

    circle-info

    Configuring WinRM to use HTTPS encrypts data transmitted between the client and server, protecting sensitive information from interception. To enable HTTPS, ensure a valid server authentication certificate is installed on the target machine.

    You can now .

    From the dropdown menu, select a connector.

    DNS name or IP address of the RDP server to connect

    WinRM Port

    WinRM port value for the server By default, Apono sets this value to 5985.

    RDP Port

    (Optional) RDP port value By default, Apono sets this value to 3389.

    Use SSL connection

    Encrypted or unencrypted connection indicator Possible Values:

    • false: Unencrypted (unsecure) connection

    • true: Encrypted (secure) connection

  • Click Next. The Secret Store section expands.

  • Associate the secret or credentials.

  • Click Next. The Get more with Apono section expands.

  • Define the Get more with Apono settings.

    Setting
    Description

    Credential Rotation

    (Optional) Number of days after which the database credentials must be rotated Learn more about the .

    User cleanup after access is revoked (in days)

    (Optional) Defines the number of days after access has been revoked that the user should be deleted

    Learn more about .

    Custom Access Details

    (Optional) Instructions explaining how to access this integration's resources Upon accessing an integration, a message with these instructions will be displayed to end users in the User Portal. The message may include up to 400 characters. To view the message as it appears to end users, click Preview.

    Integration Owner

  • Click Confirm.

  • Click to copy the code.
  • Make any additional edits.

  • Deploy the code in your Terraform.

  • Refer to Integration Config Metadataarrow-up-right for more details about the schema definition.

    Apono Connector

    On-prem connection serving as a bridge between an RDP server and Apono:

    • AWS

    • Azure

    • GCP

    User

    Microsoft RDP user for Apono The RDP user must be one of the following:

    • Admin user

    • Custom role user with the following permissions:

      • GenericRead

      • ListChildren

      • CreateChild

      • DeleteChild

      • ListObject

      • WriteMember

      • ResetPassword

      • Delete

    Secret

    Value generated with the credentials of the user you create

    Create your secret based on the connector you are using.

    You can also input the user credentials directly.

    Apono does not store credentials. The Apono Connector uses the secret to communicate with services in your environment and separate the Apono web app from the environment for maximal security.

    Integration Name

    Unique, alphanumeric, user-friendly name used to identify this integration when constructing an access flow

    unencrypted
    encrypted
    Catalogarrow-up-right
    AWS
    Azure
    GCP
    Kubernetes
    create access flows
    RDP tile

    Host

    winrm quickconfig
    winrm set winrm/config/service @{AllowUnencrypted="true"}
    winrm set winrm/config/service/Auth @{Basic="true"}

    Item

    Description

    Apono Connector

    On-prem connection serving as a bridge between a Windows DC server and Apono:

    • ​​

    • ​

    • ​​

    User

    Windows Domain Controller user for Apono The Windows Domain Controller user must be one of the following:

    • Admin user

    • Custom role user with the following permissions:

      • GenericRead

    Secret

    Value generated with the credentials of the user you create based on the connector you are using. ​

    Apono does not store credentials. The Apono Connector uses the secret to communicate with services in your environment and separates the Apono web app from the environment for maximal .

    ​


    hashtag
    Configure the Windows Domain Controller

    Before you begin integrating Windows Domain Controller with Apono, you must allow remote access with the Windows Remote Management (WinRM) service on your Windows machine.

    You can allow unencrypted or encrypted communication.

    hashtag
    Unencrypted Communication

    Follow these steps to configure the Windows Domain Controller:

    1. Add the WinRM port 5985 to the allowlist in the server firewall.

    2. Turn on the WinRM firewall rule in the Windows server.

    3. Analyze and configure the WinRM service to allow remote management on the local machine.

    circle-info

    If a confirmation prompt appears after running the following command, enter y.

    1. Set the WinRM service configuration to allow unencrypted traffic.

    1. Enable basic authentication for the WinRM service. Basic authentication transmits credentials in cleartext.

    You can now integrate the Windows Domain Controller.

    hashtag
    Encrypted Communication

    Follow these steps to configure the Windows Domain Controller:

    1. Add the WinRM port 5985 to the allowlist in the server firewall.

    2. Turn on the WinRM firewall rule in the Windows server.

    3. Analyze and configure the WinRM service to allow remote management on the local machine.

    circle-info

    If a confirmation prompt appears after running the following command, enter y.

    1. Enable basic authentication for the WinRM service. Basic authentication transmits credentials in cleartext.Shell

    1. Configure WinRM HTTPS access on the target machine.

    circle-info

    Configuring WinRM to use HTTPS encrypts data transmitted between the client and server, protecting sensitive information from interception. To enable HTTPS, ensure a valid server authentication certificate is installed on the target machine.

    You can now integrate the Windows Domain Controller.


    hashtag
    Integrate a Windows Domain Controller

    circle-exclamation

    WinRM HTTPS requires a local computer Server Authentication certificate with a CN matching the hostname to be installed. The certificate must not be expired, revoked, or self-signed.

    circle-check

    You can also use the steps below to integrate with Apono using Terraform.

    In step 11, instead of clicking Confirm, follow the Are you integrating with Apono using Terraform? guidance.

    Follow these steps to complete the integration:

    1. On the Catalogarrow-up-right tab, click Windows Domain Controller. The Connect Integration page appears.

    2. Under Discovery, select one or multiple resource types for Apono to discover in all instances of the environment.

    3. Click Next. The Apono connector section expands.

    4. From the dropdown menu, select a connector.

    circle-check

    If the desired connector is not listed, click + Add new connector and follow the instructions for creating a connector (AWS, Azure, GCP, Kubernetes).

    1. Click Next. The Integration Config page appears.

    2. Define the Integration Config settings.

      Setting
      Description

      Integration Name

      Unique, alphanumeric, user-friendly name used to identify this integration when constructing an access flow

    3. Click Next. The Secret Store section expands.

    4. .

    5. Click Next. The Get more with Apono section expands.

    6. Define the Get more with Apono settings.

      Setting
      Description
    7. Click Confirm.

    chevron-right💡Are you integrating with Apono using Terraform?hashtag

    If you want to integrate with Apono using Terraform, follow these steps instead of clicking Confirm:

    1. At the top of the screen, click View as Code. A modal appears with the completed Terraform configuration code.

    2. Click to copy the code.

    3. Make any additional edits.

    4. Deploy the code in your Terraform.

    Refer to for more details about the schema definition.

    Now that you have completed this integration, you can create access flows that grant permission to your Windows Domain Controller.

    winrm quickconfig
    winrm set winrm/config/service @{AllowUnencrypted="true"}
    winrm set winrm/config/service/Auth @{Basic="true"}
    winrm quickconfig
    winrm set winrm/config/service/Auth @{Basic="true"}

    (Optional) Fallback approver if no resource owner is found Follow these steps to define one or several integration owners:

    1. From the Attribute dropdown menu, select User or Group under the relevant identity provider (IdP) platform.

    2. From the Value dropdown menu, select one or multiple users or groups.

    NOTE: When Resource Owner is defined, an Integration Owner must be defined.

    Resource Owner

    (Optional) Group or role responsible for managing access approvals or rejections for the resource Follow these steps to define one or several resource owners:

    1. Enter a Key name. This value is the name of the tag created in your cloud environment.

    2. From the Attribute dropdown menu, select an attribute under the IdP platform to which the key name is associated. Apono will use the value associated with the key (tag) to identify the resource owner. When you update the membership of the group or role in your IdP platform, this change is also reflected in Apono.

    NOTE: When this setting is defined, an Integration Owner must also be defined.

    integrate an RDP server
    Kubernetes
    Credentials Rotation Policy
    Periodic User Cleanup & Deletion
    winrm quickconfig
    winrm set winrm/config/service/Auth @{Basic="true"}

    Resource Owner

    (Optional) Group or role responsible for managing access approvals or rejections for the resource Follow these steps to define one or several :

    1. Enter a Key name. This value is the name of the tag created in your cloud environment.

    2. From the Attribute dropdown menu, select an attribute under the IdP platform to which the key name is associated. Apono will use the value associated with the key (tag) to identify the resource owner. When you update the membership of the group or role in your IdP platform, this change is also reflected in Apono.

    NOTE: When this setting is defined, an

    ​Kubernetes​

  • ListChildren

  • CreateChild

  • DeleteChild

  • ListObject

  • WriteMember

  • ResetPassword

  • Delete

  • Host

    DNS name or IP address of the RDP server to connect

    WinRM Port

    WinRM port value for the server By default, Apono sets this value to 5985.

    RDP Port

    (Optional) RDP port value By default, Apono sets this value to 3389.

    Use SSL connection

    Encrypted or unencrypted connection indicator Possible Values:

    • false: Unencrypted (unsecure) connection

    • true: Encrypted (secure) connection

    Credential Rotation

    (Optional) Number of days after which the database credentials must be rotated Learn more about the Credentials Rotation Policy.

    User cleanup after access is revoked (in days)

    (Optional) Defines the number of days after access has been revoked that the user should be deleted

    Learn more about Periodic User Cleanup & Deletion.

    Custom Access Details

    (Optional) Instructions explaining how to access this integration's resources Upon accessing an integration, a message with these instructions will be displayed to end users in the User Portal. The message may include up to 400 characters. To view the message as it appears to end users, click Preview.

    Integration Owner

    Associate the secret or credentials
    Integration Config Metadataarrow-up-right
    AWS
    Azure
    GCP
    Create your secret
    security

    (Optional) Fallback approver if no is found Follow these steps to define one or several integration owners:

    1. From the Attribute dropdown menu, select User or Group under the relevant identity provider (IdP) platform.

    2. From the Value dropdown menu, select one or multiple users or groups.

    NOTE: When Resource Owner is defined, an Integration Owner

    must be defined.
    Integration Owner
    must also be defined.
    resource owner
    resource owners
